Linear Drivers

Eaglerise Linear LED Drivers – High-Performance Lighting Solutions


As a leading LED Driver Manufacturer, Eaglerise specializes in advanced linear LED driver, delivering efficient, reliable, and cost-effective solutions for commercial, industrial, and residential lighting applications. Our linear LED drivers provide precise constant current regulation, ensuring uniform brightness and flicker-free illumination.


The Importance of LED Drivers

LED technology is a groundbreaking lighting system, widely recognized for its longevity and energy-efficient characteristics. Typically, LEDs operate within a low direct current (DC) voltage range of 12 to 24 V. However, the standard voltage supply often ranges from 85 to 264 V in alternating current (AC), with a frequency of either 50 Hz or 60 Hz. Therefore, it is essential to convert AC power to the lower DC voltage suitable for LED operation.


A Linear LED Driver is a specially designed voltage conversion device that enables LEDs to function by supplying the required voltage. These drivers serve as dedicated power sources, performing the AC-to-DC conversion process. They ensure that the LED light sources receive consistent power for stable performance.


LEDs have specific current ratings, and any deviation from this range can impact their brightness. Fluctuations in current can cause variations in light output, leading to increased heat generation that reduces the overall performance of the LED. Excessive heat can cause the forward voltage of the LED to decrease, potentially resulting in LED failure if the power supply continues to provide the rated forward voltage under high temperatures.


Excessive heat buildup can lead to detrimental effects and permanent damage to LEDs. A Linear LED Driver plays a critical role in safeguarding the LED lights from voltage and current fluctuations. It adjusts both the current and voltage within the LED circuit, ensuring optimal brightness, prolonged battery life, and extended LED lifespan. Maintaining the voltage and current within the rated levels is vital for the efficient operation of the LED circuit, and the Linear LED Driver ensures this is consistently achieved.


Key Features Of Linear LED Drivers


Constant Current Regulation: Maintains stable output current for consistent LED performance.

Wide Voltage Range: Compatible with high/low-voltage applications.

Compact Design: Compliant with ZHAGA protocol, ideal for space-constrained applications.

Full Protection: Short circuit protection, over load protection, over temperature protection, over voltage protection.


Wholesale options for linear LED driver


1.Non-isolated LED drivers:Best suited for cost-sensitive, space-constrained projects such as warehouse lighting (tri-proof lights).

2.Isolated LED drivers:Designed for high-safety environments and regulated markets, isolated linear LED drivers are ideal for commercial spaces such as offices and hotels (LED linear lights) where galvanic isolation is critical to prevent electric shock risks. They are also preferred in public infrastructure (airports) due to compliance with strict safety standards like UL/IEC.


Applications

Eaglerise linear LED drivers power diverse lighting systems, including:

Commercial Lighting: LED linear lights.

Warehouse Lighting: Tri-proof lights.

Smart Lighting: Bluetooth/DALI-dimmable solutions for IoT-enabled environments.


You can choose the appropriate linear LED driver based on the usage scenario, current requirements, energy efficiency, cost, etc. Contact us to help you design your own custom LED driver solutions.
